| NO | Item | Parameter | ||
| GHQ250-700 | GHQ360-900 | |||
| 1 | Oil Cylinder Pressure | 1600KN | 3150KN | |
| 2 | Dual Bending Range | L80*7mm～L250*32mm | L80*7～L 360*40mm | |
| 3 | Dual Bending Angle | 30° | ||
| 4 | Processing range of positive single bending | L80*7mm～L200mm*18mm | L100*10mm～L300*30mm | |
| 5 | Positive single bending angle | 20° | ||
| 6 | Thickness of curved plate | 2mm～16mm | 2mm～20mm | |
| 7 | Processing width of curved plate | 700mm | 900mm | |
| 8 | Bending angle of curved plate | 90° | ||
| 9 | Oil cylinder stroke | 800mm | ||
| 10 | Machine power | 15KW | 22KW | |
| 11 | Heating power | 60*2KW | 80*2KW | |
| 12 | CNC Axis Numbers | 3 | ||
| 13 | Cooling water tank | 6 m³ | ||
| 14 | Cooling tower flow rate | 50 m³/h | ||
| 15 | Water Tank volume | 630L | ||
| 16 | Machine weight | about 8 Tons | about 12Tons | |
| 17 | Machine Overall Dimensions | 3500 mm *4500 mm *4100 mm | 4200mm*4500mm*4100mm | |
| NO | Name | Mode | Unit | Quantity | Remark |
| 1 | Spindle | GHQ360～700 | Set | 1 | equipment |
| 2 | Control cabinet | GHQ360～700 | Set | 1 | equipment |
| 3 | Hydraulic system | GHQ360～700 | Set | 1 | equipment |
| 4 | heater | JR-60 | Set | 2 | equipment |
| 5 | Heating Spindle | JR-60 | Set | 2 | equipment |
| 6 | Hyperbolic mold | GHQ360～700 | Set | 1 | equipment |
| 7 | Single mold | GHQ360～700 | Set | 1 | equipment |
| 8 | Curved plate mould | GHQ360～700 | Set | 1 | equipment |
| 9 | Lower die base | GHQ360～700 | Set | 2 | equipment |
| 10 | Upper mold support | GHQ360～700 | Set | 1 | equipment |
| 11 | Induction loop | GHQ360～700 | Set | 2 | equipment |
| 12 | Double end open end wrench | 24*27 |
| 1 | tool |
| 13 | Adjustable wrench | 250mm | pic | 1 | tool |
| 14 | Inner hexagon spanner | 4#-14# | Set | 1 | tool |
| 15 | Inner hexagon spanner | 12mm | pic | 1 | tool |
| 16 | Slotted screwdriver | 6*150 | pic | 1 | tool |
| 17 | Cross screwdriver | PH2*150 | pic | 1 | tool |
| 18 | High pressure machine oil pot | 250ml | pic | 1 | tool |
| 19 | Equipment manual | Set | 2 | document | |
| 20 | Combined washer | GHQ360～700 | Set | 1 | parts |
| 21 | Equipment safety operation procedures | Set | 2 | document | |
| 22 | Equipment certificate | Set | 2 | document | |
| 23 | Delivery receipt | Set | 1 | document | |
| 24 | Equipment acceptance form | Set | 1 | document |
3. Angle steel bending machine, to achieve a machine for multiple purposes, do not need to be equipped with other tooling mold. 4. CNC system ensures the curving angle of the material (angle profile or steel plate), ensures the quality of products and improves the production efficiency. 5. Angle Steel Heating Bending Machine has independent hydraulic system and electrical control system, which is simple and convenient to operate, safe and reliable in performance, with production efficiency.
6. Angle profile processed by angle steel bending machine is less than L100 × L100 × 10 bending degree less than 5 ° Cold pressing can be used. 7. Processing speed: cold pressing for 10s / time, heating processing for 120s / time (determined according to actual processing materials and materials) when the heating temperature is 800 (i.e. red), the material is processed (determined according to the actual material and bending angle).
8. When the material is heated, design the parameters, press the cycle start or step down the foot switch to complete the heating forward, heating, heating exit, pressing the material, raising the head and taking out the material automatically. 9. When heating and cold pressing, the parameters are designed and the cold pressing is carried out directly. The pressing head does not need to return to the origin. The pressing die raises the clearance of 100 mm and takes out the material. The work efficiency is high.
