| Series No. | Item name | Parameters | |
| 1 | Host motor power | 15kW | |
| 2 | Saw blade size(mm) | T:1.6 W:67 C:9300 | |
| 3 | Saw blade speed | 20-100m/min (can be adjusted) | |
| 4 | Sawing ability (H-beams, mm) | Sawing at 90° | Max: 1250x600 |
| 5 | Min: 200x75 | ||
| 6 | Sawing at 45° | Max: 750x600 | |
| 7 | Rotation angle | 0°～45° | |
| 8 | Table height | 800mm | |
| 9 | Overall Dimension | Width:4400mm | |
| 10 | Length:2800mm | ||
| 11 | Height:2820mm | ||
| 12 | Temperature of working environment | 0℃～40℃ | |
| 13 | Specification of power | Three phase four wire system, AC Voltage: 380V±10%, Frequency：50 HZ. | |
| 14 | Weight of machine | (Approx)10000kg | |
| NO. | Name | Band | Country |
| 1 | Linear guide rail | HIWIN/CSK | Taiwan(China) |
| 2 | Hydraulic motor | Justmark | Taiwan(China) |
| 3 | Magnescale | SIKO | Germany |
| 4 | Hydraulic pump | Justmark | Taiwan(China) |
| 5 | Electromagnetic hydraulic valve | ATOS/YUKEN | Italy / Japan |
| 6 | Proportional valve | ATOS | Italy |
| 7 | Saw blade | LENOX/WIKUS | USA / Germany |
| 8 | Frequency converter | INVT/INOVANCE | China |
| 9 | Programmable controller | Mitsubishi | Japan |
| 10 | Servo motor | PANASONIC | Japan |
| 11 | Servo driver | PANASONIC | Japan |
| 12 | Touch screen | Panel | Taiwan(China) |
3.The saw frame adopts hydraulic servo proportional valve and encoder, which can realize digital feeding. 4.The machine tool has the main motor current detection function, when the motor overload operation, This sawing machine can use part reciprocating cutting function to prevent the saw from clamping.
5.The rotary table adopts frame structure, with good rigidity, strong stability and smooth sawing section. 6.The band saw blade adopts hydraulic tension, which can maintain good tension force in rapid movement, extending the service life of the saw blade.
7.Sawdust automatic cleaning system is equipped with a power rotary brush on the saw blade frame to automatically clean the iron chips that may stick to the saw blade after cutting. 8.The machine has the turning function of turning 0°～45°: the material does not move but the whole machine rotates, then 0 °～ 45° Any angle between them.
